Technical Details

• Package / Case 16-WQFN Exposed Pad
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 125°C (TA)
• On-State Resistance (Max) 2.4Ohm
• -3db Bandwidth 35MHz
• Supplier Device Package 16-WQFN (4x4)
• Voltage - Supply, Single (V+) 4.5V ~ 44V
• Charge Injection 104pC
• Switch Circuit SPDT - NO/NC
• Multiplexer/Demultiplexer Circuit 2:1
• Channel-to-Channel Matching (ΔRon) 100mOhm (Typ)
• Switch Time (Ton, Toff) (Max) 130ns, 160ns
• Channel Capacitance (CS(off), CD(off)) 45pF, 55pF
• Current - Leakage (IS(off)) (Max) 1nA
• Number of Circuits 2
